Product sawifiahna .
-A .Capacitive 15.6-inch touch panel a awm a ni.Ilitek Touch Controller hmang hian IC hian a chung lamah gloves thick,thick tempered glass leh thick PC hmangin operation a support thei a, hei hi industrial, medical, outdoor advertisement leh hmanraw dang dangah hman a ni ber. Deep customization structural, surface treatment Ag ar AF leh special effect dangte pawh a thlawp a; A chi hrang hrang Interface conversion board leh drive board te chu customer hrang hrang atanga thil mamawh phuhruk turin pek a nih chuan.
-A .PCAP 10 a ni.15.6 inch touch panel hi 1920x1080 resolution display screen nen a inmil a, USB leh H-DMI interface hmangin i device nen a inzawm a, i lei hnuah direct-in i hmang thei ang.
-Customist solutions kan pe thei a, chu chu customer mamawh angin a siam a ni. Kan 15.6-inch touch panel hi client-in specification a pek angin a shape, a rawng, a cover glass size, a thickness, a logo leh additional elements dang a siam theih a ni.
Product sawifiahna .
| Model number 100 a ni. | HX1561704 a ni. |
| Chhinchhiah | Grahowlet a ni a. |
| Lenzawng tehna | 15.6 inch a ni. |
| Interface chi hrang hrang . | USB/IIC/RS232 a ni. |
| Ruangam | G+G |
| Controller IC 1000 a ni. | Ilitek 100 a ni. |
| touch points . | Point 10 a hmu a ni. |
| Transparency 1000 a ni. | 85% aia tam emaw, a tlukpui emaw . |
| Surface Hardness . | 6H aia tam emaw, a tlukpui emaw . |
| Hnathawh dan tur . | -20℃- 70℃, 85% RH aia tlem emaw, a tlukpui emaw |
| A dahna tur boruak . | -30℃- 80℃, 85% rh aia tlem emaw, a tlukpui emaw |
| Power supply voltage a ni a, a hlawhtling hle. | 5 V |
| Outline dimension 1000 a ni. | 389.00(w)x237.05(h)x2.00(d) mm 1000 a ni. |
| En theihna hmun . | 345.43(w)x194.74(h) mm ah a awm a. |
| Support system hrang hrang . | Windows/Android/Linux etc. ah te a awm a. |
| Warranty a awm em? | Kum 1 . |
FAQ a ni.
Q: I company thil siam ber ber, process leh size range te min hrilh thei ang em?
A: Kan thil siam ber berte chu: Glass cover bik, capacitive touch screen, LCD screen, capacitive touch screen module, driving board support
Technical Process: G+G structure, P+G structure leh GFF structure, flexible touch screen, bonding process: Air bonding & optical bonding.Size range 1.3 inch atanga 65 inch inkar a ni a, tunah hian batch production-ah size 65 inch aia sang nei project a awm lo.
Q: Industry-a hman capacitive screens hian industry characteristics avang hian special function thenkhat a support a ngai fo thin a, industrial capacitive touch screens i siam ber avangin, he lamah hian technical accumulation i nei em?
A: Ni e, i sawi dik e. Industrial capacitive screen atan hian special function tam tak a awm a, entirnan, pawn lama hman tur emaw, environment-a tui awmna product thenkhat emaw atan chuan capacitive touch screens ngei pawh hian tui touch an support a ngai a, tuipui hmanrua hmanna atan pawh nise, sea touch leh 5% saline water touch an support a ngai a ni. Industrial hmanna hmun thianghlim thenkhatah chuan hnathawk thenkhat chuan gloves hmangin an thawk fo ang a, boruak hian organic oil pawh a nei thei bawk a, chuvangin capacitive touch screen ngei pawhin glove operation leh anti-oil pollution function a thlawp a ngai a;chutah chuan, entirnan, pawn lam thil thenkhat emaw special field application product thenkhat emaw chuan explosion-proof leh shock{{5} protected, the surface of deviced, so it needs the surface the surface temper will be the surface the capacit screen will bet the so it needs Capacitive screen ngei pawh hi a cover thick tak hmanga operation function a support theih nan. A tlangpuiin, tunah hian capacitive screen supporting water, glove operation leh oil resistant function, thick cover leh a dangte lam hawiin technical accumulation engemaw zat kan nei a. A chipchiar zawkna chu kan technician-te nen dinhmun tak tak atanga thlirin kan sawiho thei a ni.
Contact kan nei em:hongxiao@grahowlet.com
hot tags .: 15.6 inch touch panel, China 15.6 inch touch panel supplier te, siamtu te, factory te
